Technical Data
Vibration frequency: 4000-4800 per/min
Cycle time: 15-20(s)
Total Power: 25.5(KW)
Total weight: 7000kg
Exciting force: 18KN
Pallet pattern: 860x540x20(mm) (Bamboo gum plank)
Shape size: 12550x2210x1900(mm)
Specification of the Bricks and the Production Capacities for Different Bricks
Items Size (LXWXH) Pieces./mould Pieces./hour Pieces./8hour
Hollow Block 390x190x190 4 576 4,608
Porous Bricks 240x115x90 12 1,728 13,824
Dimension Bricks 240x115x53 24 3,456 27,648
Dimension Bricks 240x115x50 26 3,744 29,952
