n Engine Model                       6BTAA5.9 Rated power                            112KW Rated RPM                            1950r/min Displacement                             5.9L Mox torque                              202N.m Hydraulic pressure       31.9/34.3Mpa  Swing speed                          11.6rpm Bucket capacity                         1.1m3 Carrier roller                       2 units each side Track roller                      8 units each side Track shoe width                    600mm Track chain                47 units each side  Drive model                Whole hydraulic drive Drive motor                     Axial piston motor Max. travel speed                3.33/5.54km/h Grade ability   35°  Operating weight                       21800kg  Bucket digging force                     128KN Bucket rod digging force                  99KN
	Specification Engine Model                       6BTAA5.9 Rated power                            112KW Rated RPM                            1950r/min Displacement                             5.9L Mox torque                              202N.m Hydraulic pressure       31.9/34.3Mpa  Swing speed                          11.6rpm Bucket capacity                         1.1m3 Carrier roller                       2 units each side Track roller                      8 units each side Track shoe width                    600mm Track chain                47 units each side  Drive model                Whole hydraulic drive Drive motor                     Axial piston motor Max. travel speed                3.33/5.54km/h Grade ability   35°  Operating weight                       21800kg  Bucket digging force                     128KN Bucket rod digging force                  99KN
