Engine: 336hp

Transmission: PT-11509C

Tires: 12:00-20

Axle Space: 3600+1350mm

With air condition

Mixer Tank Volume (m³): 14.9

Valid Mixing Volume (m³): 8

Barrel Wall Thickness : 5mm

Mixing Blades thicknessl: 4mm

Loading Speed (m³/min): =  3.2

Discharging Speed(m³/min): =  2.2

Rest rate (%): =  1

Mixer Speed (rpm): 0-16

Mixer Tank angle: 13°



Driving system

(hydraulically controlled) Speed Reduction System: TOPP68/TOP (made in Italy)

Pump: 5423-518/Eaton (made in USA)

Motor Model: 5433-138/Eaton (made in USA)
